Audio Technica LPW40WN
Information
Audio Technica LPW40WN Manual Turntable
The Audio Technica LPW40WN Manual Turntable is a fully manual, belt-drive turntable designed to give you optimal high-fidelity audio reproduction from vinyl. It features an aesthetically pleasing anti-resonance MDF (medium density fiberboard) plinth with simulated walnut wood veneer to limit low-frequency acoustical feedback and a sensor-monitored motor to ensure accurate platter rotation speeds at 33-1/3 and 45 RPM.
The turntable includes a straight carbon-fiber tonearm with adjustable tracking force and an AT-HS4 universal ½”-mount headshell with an AT-VM95E Dual Moving Magnet phono cartridge. Audio-Technica has been a leader in phono cartridge design for more than 50 years, and that expertise shows in the versatile, high-performance AT-VM95E cartridge, which comes with a 0.3 x 0.7 mil elliptical stylus, but is also compatible with any VM95 Series replacement stylus, offering a wide choice of options for every budget and application.
The AT-LPW40WN is equipped with a built-in selectable phono preamp and a detachable dual RCA output cable to enable direct connection to components with or without a dedicated phono input.
Audio Aesthetics
The LPW40WN was designed to give you optimal high-fidelity audio reproduction with smart styling.
Stylish Wood Turntable
A stunning addition to any system, the AT-LPW40WN features an anti-resonance plinth with simulated walnut wood veneer to limit low-frequency acoustic feedback.
Over 55 Years of Analog Excellence
We got our start in Tokyo in 1962, designing and manufacturing high-performance phono cartridges. That half-century’s worth of analog expertise goes into every turntable we produce, ensuring you get the best listening experience from your vinyl.
SPECIFICATIONS
| Type | 2-speed, fully manual operation |
| Motor | DC servo motor w/speed stability control |
| Drive Method | Belt drive |
| Speeds | 33-1/3 RPM, 45 RPM |
| Turntable Platter | Die-cast aluminium |
| Wow and Flutter | 0.15% (WTD) @ 3 kHz (JIS) |
| Signal-to-Noise Ratio | >60dB |
| Output Level | Pre-amp “PHONO”: 4 mV nominal at 1 kHz, 5 cm/sec Pre-amp “LINE”: 200 mV nominal at 1 kHz, 5 cm/sec |
| Phono Pre-Amp Gain | 35 dB nominal, RIAA equalized |
| Power Supply Requirements | 100-240V AC, 60 Hz |
| Power Consumption | 1 W |
| Dimensions | 420.0mm W x 340.0mm D x 116.9mm H |
| Weight | 4.7kg |
| Accessories Included | AT-VM95E phono cartridge; AT-HS4 headshell; dual RCA (male) to dual RCA (male) cable with ground wire; counterweight; rubber mat; dust cover; 45 RPM adapter |
| Tonearm type | Balanced straight tonearm with detachable headshell |
| Effective arm length | 223.6mm |
| Overhang | 18.6mm |
| Tracking error angle | <2 degrees |
| Applicable cartridge weight | 12-17g |
| Anti-skating range | 0-3g |
| Replacement Stylus | AT-VMN95E |
